SER65091 - Wire output with consumption measurement

Product Description

The connected 20A cable output is a recessed, mains-powered device for controlling a load up to 20A (typically a heating appliance connected via a cable outlet). Connected over Bluetooth Mesh, it is configured and controlled via the mobile App (control, scenario/thermostat integration) and reports energy consumption metering.

REF13.1 3D

Item code : SER65091
Internal ref. : REF13.1

Technical Specifications

Power supply: 230V AC ~50Hz
Connectivity: Bluetooth Mesh
Dimensions: To be completed
Output: 100-230V AC 20A
Operating temperature: 10°C - 60°C
Mounting: Connected cable outlet, recessed installation

Maximum load limits

Load type	Wiring	Min power	Max power	Max current	Per output
Resistive (cos φ = 1)			3500W	16A
Other (motors, LED…)			1000W	4.3A

Supported Functions

Control

Heating management : Heating appliance management

Automation

Scenario management · Vigilant Home

Energy & Sensors

Energy consumption measurement · Electrical flexibility management · Off-peak control

Security

Overheat alert · Power outage alert

Standard range functions

Product interfaces · Power supplies · Product health indication · User account · Software updates · Bluetooth Mesh connectivity functions · Voice assistant compatibility

Electrical Installation

Interfaces

../../../_images/REF13.1_wirings_interfaces.png

Mains connection

Warning

!! ELECTROCUTION HAZARD !! Before wiring this product, carefully read this warning: Electrocution Hazard

Output wiring Cable outlet

../../../_images/REF13.1_wirings_output-heater-cable-outlet.png

Output assignment :

Heating management - Heating appliance management

Functional Setup

Once the product is electrically installed, you can power it on.

You can then start the functional setup from the mobile App.

Revision date : Oct 13, 2026
