SER65090 - Wire output for Pilot Wire
Product Description
This connected module allows remote control of electric heaters via an app. Quick and easy to install, it offers smart heating management for optimized comfort and energy savings.
Item code : SER65090
Internal ref. : REF11.1
Technical Specifications
Power supply: 230V AC ~50Hz
Connectivity: Bluetooth Mesh
Dimensions: 42x35x10mm
Output: 100-230V AC 5A
Operating temperature: 10°C - 60°C
Mounting: Fits inside the radiator’s electrical inlet
Maximum load limits
Load type |
Wiring |
Min power |
Max power |
Max current |
Per output |
|---|---|---|---|---|---|
Halogen |
No neutral (2-wire) |
5W |
200W |
||
Halogen |
With neutral (3-wire) |
200W |
|||
LED |
No neutral (2-wire) |
5VA |
100VA |
||
LED |
With neutral (3-wire) |
100VA |
Supported Functions
Control
Automation
Energy & Sensors
Energy consumption measurement · Electrical flexibility management
Security
Overheat alert · Power outage alert
Standard range functions
Product interfaces · Power supplies · Product health indication · User account · Software updates · Bluetooth Mesh connectivity functions · Voice assistant compatibility
Electrical Installation
Interfaces
Mains connection
Warning
!! ELECTROCUTION HAZARD !! Before wiring this product, carefully read this warning: Electrocution Hazard
Output wiring Pilot wire output 4 modes
Output assignment :
Output wiring Pilot wire output 6 modes
Output assignment :
Functional Setup
Once the product is electrically installed, you can power it on.
You can then start the functional setup from the mobile App.
Revision date : Oct 13, 2026
