Product Description
The gate micro-module is a recessed, mains-powered module dedicated to controlling a front gate or garage door within the Bluetooth Mesh ecosystem.
Configured via the mobile App, it lets you control opening/closing from the app, scenarios, or voice assistants.
The product includes the range’s general functions: status LEDs, Reset button, energy consumption metering, safety functions (overheat alert, power outage, zero-load detection), full Bluetooth Mesh connectivity (Proxy, Relay and Friend roles) and software updates via the app.
Item code : SER65079
Internal ref. : REF12.1
Technical Specifications
Power supply: 230V AC ~50Hz
Connectivity: Bluetooth Mesh
Dimensions: To be completed
Operating temperature: 10°C - 60°C
Mounting: Fits inside a recessed box
Maximum load limits
Load type |
Wiring |
Min power |
Max power |
Max current |
Per output |
|---|---|---|---|---|---|
Resistive (cos φ = 1) |
700W |
3A |
Yes |
||
Other (motors, LED…) |
500W |
2.2A |
Yes |
Supported Functions
Control
Energy & Sensors
Energy consumption measurement
Security
Overheat alert · Power outage alert
Standard range functions
Product interfaces · Power supplies · Product health indication · User account · Software updates · Bluetooth Mesh connectivity functions · Voice assistant compatibility
Electrical Installation
Interfaces
Mains connection
Warning
!! ELECTROCUTION HAZARD !! Before wiring this product, carefully read this warning: Electrocution Hazard
Output wiring Gate
Output assignment :
Output wiring Garage door
Output assignment :
Functional Setup
Once the product is electrically installed, you can power it on.
You can then start the functional setup from the mobile App.
