SER65060 - Recessed outlet with consumption measurement
Product Description
The connected 2P+T 16A socket is a controllable mains socket, integrated into the Bluetooth Mesh ecosystem, allowing you to control a 230V load up to 16A from the mobile App. Depending on the configuration chosen, it can be used for socket / lighting use cases (On/Off control).
It also includes energy consumption metering, integration with scenarios and Vigilant Home, voice assistant compatibility, as well as safety functions (e.g. overheat alert, power outage, zero-load detection) and software updates via the app.
Item code : SER65060
Internal ref. : REF13.2
Technical Specifications
Power supply: 230V AC ~50Hz
Connectivity: Bluetooth Mesh
Dimensions: To be completed
Operating temperature: 10°C - 60°C
Mounting: Standard 16A wall socket
Maximum load limits
Load type |
Wiring |
Min power |
Max power |
Max current |
Per output |
|---|---|---|---|---|---|
Resistive (cos φ = 1) |
3500W |
16A |
|||
Other (motors, LED…) |
1000W |
4.3A |
Supported Functions
Control
Automation
Scenario management · Vigilant Home
Energy & Sensors
Energy consumption measurement · Electrical flexibility management · Off-peak control
Security
Overheat alert · Power outage alert · Zero-load detection
Standard range functions
Product interfaces · Power supplies · Product health indication · User account · Software updates · Bluetooth Mesh connectivity functions · Voice assistant compatibility
Electrical Installation
Interfaces
Mains connection
Warning
!! ELECTROCUTION HAZARD !! Before wiring this product, carefully read this warning: Electrocution Hazard
Output wiring On/Off (light bulb)
Output assignment :
Output wiring On/Off (plug)
Output assignment :
Functional Setup
Once the product is electrically installed, you can power it on.
You can then start the functional setup from the mobile App.
Revision date : Oct 13, 2026
