SER65077 - Chime
Product Description
The chime micro-module is a recessed, mains-powered module dedicated to controlling a chime within the Bluetooth Mesh ecosystem.
Configured via the mobile App, it lets you trigger the chime from the app, scenarios, or voice assistants.
The product includes the range’s general functions: status LEDs, Reset button, energy consumption metering, safety functions (overheat alert, power outage, zero-load detection), full Bluetooth Mesh connectivity (Proxy, Relay and Friend roles) and software updates via the app.
Item code : SER65077
Internal ref. : REF12.2
Technical Specifications
Power supply: 230V AC ~50Hz
Connectivity: Bluetooth Mesh
Dimensions: To be completed
Operating temperature: 10°C - 60°C
Mounting: Fits inside a recessed box
Maximum load limits
Load type |
Wiring |
Min power |
Max power |
Max current |
Per output |
|---|---|---|---|---|---|
Resistive (cos φ = 1) |
700W |
3A |
Yes |
||
Other (motors, LED…) |
500W |
2.2A |
Yes |
Supported Functions
Control
Energy & Sensors
Energy consumption measurement
Security
Overheat alert · Power outage alert
Standard range functions
Product interfaces · Power supplies · Product health indication · User account · Software updates · Bluetooth Mesh connectivity functions · Voice assistant compatibility
Electrical Installation
Interfaces
Mains connection
Warning
!! ELECTROCUTION HAZARD !! Before wiring this product, carefully read this warning: Electrocution Hazard
Output wiring Chime
Output assignment :
Functional Setup
Once the product is electrically installed, you can power it on.
You can then start the functional setup from the mobile App.
Revision date : Oct 13, 2026
