SER65021 - Integrated switch with 2 3A outputs
Product Description
The complete generic 2-output 3A switch is a wall-mounted device, mains-powered, with a built-in control input, designed to control lighting, dimming, shutters, ventilation or chime within the Bluetooth Mesh ecosystem.
Unlike the micro-module, there is no need to keep an existing switch upstream: the control button is built into the product. Motion detection can also be configured as an option.
The product includes all of the range’s general functions: status LEDs, Reset button, energy consumption metering, safety functions (overheat alert, power outage, zero-load detection), full Bluetooth Mesh connectivity (Proxy, Relay and Friend roles), voice assistant compatibility and software updates via the app.
Item code : SER65021
Internal ref. : REF12.3
Technical Specifications
Power supply: 230V AC ~50Hz
Connectivity: Bluetooth Mesh
Dimensions: To be completed
Output: 2 x 100-230V AC 3A
Operating temperature: 10°C - 60°C
Mounting: Complete wall switch, replaces an existing switch
Maximum load limits
Load type |
Wiring |
Min power |
Max power |
Max current |
Per output |
|---|---|---|---|---|---|
Resistive (cos φ = 1) |
700W |
3A |
Yes |
||
Other (motors, LED…) |
500W |
2.2A |
Yes |
Supported Functions
Control
Energy & Sensors
Energy consumption measurement · Off-peak control
Security
Overheat alert · Power outage alert · Zero-load detection
Standard range functions
Product interfaces · Power supplies · Product health indication · User account · Software updates · Bluetooth Mesh connectivity functions · Voice assistant compatibility
Electrical Installation
Interfaces
Mains connection
Warning
!! ELECTROCUTION HAZARD !! Before wiring this product, carefully read this warning: Electrocution Hazard
Input wiring 2-button/rocker switch
If the switch is a push button, you can choose an assignment for the input from the following list:
Lighting and socket management - On/Off switch (1 button required)- Lighting and socket management - Dimmer push-button (1 button required)
Doorbell and chime - Doorbell and chime (1 button required)
Shutter management - Shutter switches (2 buttons required)
Scenario management - Scenario trigger button (1 button required)
Output wiring On/Off (light bulb)
Output assignment :
Output wiring Ventilation (low/high speed or low speed + on/off)
Output assignment :
Output wiring Chime
Output assignment :
Output wiring Roller shutter
Output assignment :
Output wiring Blind
Output assignment :
Functional Setup
Once the product is electrically installed, you can power it on.
You can then start the functional setup from the mobile App.
Revision date : Oct 13, 2026
