SER65036 - Double push button with enery harvesting
Product Description
The double push-button (EnOcean BLE protocol) is a standalone wall switch that requires neither mains power nor a battery. With each press, its magnetic micro-generator (energy harvesting) produces the energy needed to instantly transmit a Bluetooth Low Energy command (Advertising mode).
It lets you control LinkIO ecosystem products (On/Off, dimming, shutters, chime, scenarios…), with the advantage of zero maintenance (no battery replacement).
Important: control is not meshed over Bluetooth Mesh — the button must stay within radio range of the products it controls. Commissioning is done via QR-Code from the mobile App.
Item code : SER65036
Internal ref. : PTM215B
Technical Specifications
Power supply: Magnetic micro-generator
Connectivity: Bluetooth Low Energy (Advertising mode)
Transmit power: 4dBm
Operating temperature: -25°C to 65°C
Humidity: 0% to 95% r.h. (non-condensing)
Dimensions: 40mm x 44mm x 11.2mm
Mounting: Free-standing
Supported Functions
Automation
Standard range functions
Electrical Installation
Interfaces
Activating the product
Functional Setup
Once the product is electrically installed, you can power it on.
You can then start the functional setup from the mobile App.
Revision date : Oct 13, 2026
