SER65065 - Cover for light connection device On/Off
Product Description
The connected ceiling rose (DCL) On/Off is a recessed device, mains-powered with or without neutral, that replaces a standard ceiling rose to switch a light point On/Off within the Bluetooth Mesh ecosystem.
Unlike the micro-module, it has no physical control input: control is done solely from the mobile App, scenarios, or voice assistants.
The product includes all of the range’s general functions:
With or without Neutral power supply
Status LEDs and Reset button
Energy consumption metering
Safety functions: overheat alert, power outage alert, zero-load detection
Full Bluetooth Mesh connectivity (provisioning / unprovisioning, configuration mode, Proxy, Relay and Friend roles)
Scenarios, Vigilant Home and voice assistant compatibility
Software update via the mobile Application
Item code : SER65065
Internal ref. : REF10.2
Technical Specifications
Power supply: 230V AC ~50Hz
Connectivity: Bluetooth Mesh
Dimensions: To be completed
Output: 100-230V AC 5A
Operating temperature: 10°C - 60°C
Mounting: Replaces a standard ceiling rose (DCL)
Maximum load limits
Load type |
Wiring |
Min power |
Max power |
Max current |
Per output |
|---|---|---|---|---|---|
Halogen |
No neutral (2-wire) |
5W |
200W |
||
Halogen |
With neutral (3-wire) |
200W |
|||
LED |
No neutral (2-wire) |
5VA |
100VA |
||
LED |
With neutral (3-wire) |
100VA |
Supported Functions
Control
Automation
Scenario management · Vigilant Home
Energy & Sensors
Energy consumption measurement · Off-peak control
Security
Overheat alert · Power outage alert · Zero-load detection
Standard range functions
Product interfaces · Power supplies · Product health indication · User account · Software updates · Bluetooth Mesh connectivity functions · Voice assistant compatibility
Electrical Installation
Interfaces
Mains connection
Warning
!! ELECTROCUTION HAZARD !! Before wiring this product, carefully read this warning: Electrocution Hazard
Output wiring On/Off (light bulb)
Avec Neutre :
Sans Neutre :
Output assignment :
Functional Setup
Once the product is electrically installed, you can power it on.
You can then start the functional setup from the mobile App.
Revision date : Oct 13, 2026
